Rear View Camera Kit for Peugeot 5008

Peugeot 5008 with OEM 10" NAC System

An integrated high quality retrofit reversing camera kit solution, designed to work with your Peugeot 5008's factory fitted infotainment system. This retrofit reversing camera kit solution, is compatible with vehicles fitted with the 10" NAC navigation touch screen system.  The solution incorporates active (Moving) guide lines and integrates with the cars parking sensors to provide a visual parking display. The rear camera will activate as soon as reverse gear is engaged. This solution is compatible with Peugeot 5008 cars manufactured from 2018 onwards.

Special Notes:

• Dynamic guidelines are only available on vehicles with Automatic transmission. Vehicles with manual transmission will have static guide lines.
• This solution is only suitable for vehicles with the 10 inch NAC system, for the 8 inch NAC system see our other listing.

Reversing Camera

This retrofit reversing camera solution includes a high quality rear view camera which features a discrete look, just like the factory fitted option. The camera will provide a clear and sharp image, the camera will also work perfectly well in damp and low light conditions.

Camera Specifications

•  2 different auxiliary lines: switched off at the factory (can be switched on)
•  black matt plastic housing with stainless steel fastening
•  Mirrored image reproduction (adjustable)
•  Image display rotated 180° (adjustable)
•  Image sensor type 1/4 '' 1233 HD Colour CMOS Low Light Sensor
•  NTSC video signal output
•  Resolution 960H480V pixels
•  DIN protection class IP69K
•  800 TV lines
•  Exposure 60 fields per seconds
•  Signal to noise ratio >46dB
•  Dynamic Range >74dB
•  Light sensitivity <0.01 Lux / F1.2
•  Output signal 1.0Vp-p, 75 OHM
•  Automatic white balance
•  Automatic video level adjustment
•  Operating voltage 12 volts DC
•  Power consumption 25-55mA
•  Diagonal viewing angle 188°
•  Horizontal viewing angle 155°
•  Vertical viewing angle 113°
•  Camera dimensions 25.8 x 28.2mm and 20.8mm high
•  8mm mounting hole
•  Working temperature -40°C to +75°C
•  Storage temperature -60°C to +105°C
•  E certified

** Manufacturing specifications are subject to change without prior notification

Benefits Of Having A Reverse Camera In Your Peugeot 5008

• Guidelines can be really helpful so the driver can accurately estimate the width of the vehicle parking space whilst reversing.
• The driver can see any obstructions behind the vehicle during the reversing manoeuvre
• The driver can see any any blind spots which are not visible to the driver
• Greater vehicle safety management during reversing manoeuvres
• Makes reversing much safer and more convenient

*Installation is optional via the dropdown

Refer to the compatibility section to check your vehicle variant is supported.

NOTE: A reversing camera kit is ONLY a Parking Aid and should not be relied on solely. Please check your surroundings at all times before carrying out a Reversing Manoeuvre. Where Guide lines are included, the guide lines are generic to all vehicles and hence fixed width and not adjustable to the width of the vehicle.
