7” Digital Media Station, featuring Apple CarPlay and Android Auto compatibility - iLX-702DCompletely integrate your phone into your car with this clever Alpine stereo. Apply CarPlay and Android Auto will let you use your phone while you drive by bringing your iPhone, Samsung, or any Android phone capable of connecting with Apple CarPlay or Android Auto up onto the radio screen. This is a legal and safe way to use your phone while you drive, the large 7” screen makes viewing and navigation through the radio easy.Features like DAB/DAB+ Digital Radio, Video Playback via USB, HDMI connectivity and built in with the latest Bluetooth technology. You even have several options for navigation: the iLX-702D includes online navigation capability to use Maps with Apple CarPlay and Google navigation with Android Auto. Both Apple CarPlay and Android Auto apps can access the Alpine navigation antenna for highest positioning accuracy.High Resolution WVGA Touch ScreenThe 7-inch (17.8cm) high-resolution WVGA display allows full operation of the system via touch-screen technology and features the latest video enhancement technology for outstanding picture clarity, contrast and resolution. This allows online navigation maps to be displayed in stunning detail, while movies or video clips become a real cinematic experience. The user interface is very intuitive and is designed to perfectly integrate into your vehicle. You can choose from a variety of screen colours and designs to best match your taste and vehicle.7-inch Screen with 1 DIN chassisMore and more vehicles feature a dashboard space for a 7-inch or 8-inch screen, however behind the screen there is no space to fit a full 2DIN product. The new SMART is for example one of the vehicles with such dashboard design. Alpine designed the iLX-702D to overcome this problem by putting a 1DIN chassis in the back of a 7-inch screen. With a car specific Alpine installation kit you can achieve a perfect installation and original manufacturer look.Works with Apple CarPlayThe innovative iLX-702D with Apple CarPlay compatibility brings you a smarter way to use your iPhone on the road. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use maps, listen to music and access messages with just a word or a touch. You can even enjoy Spotify, internet radio or podcasts while on the road for a truly connected experience. Simply connect your CarPlay enabled iPhone to the USB port of your Alpine and you are ready to go.Works with Android AutoAndroid Auto was designed with safety in mind. With a simple and intuitive interface, integrated steering wheel controls, and powerful new voice actions, it's designed to minimize distraction so you can stay focused on the road. Android Auto automatically brings you useful information, and organizes it into simple cards that appear just when they're needed. Both Apple CarPlay and Android Auto can access the navigation antenna of the iLX-702D for highest accuracy when using the navi apps.DAB+ Digital RadioThe built-in DAB/DAB+/DMB tuner uses the most advanced digital technology to deliver radio reception in outstanding, noise-free sound quality. DAB+ also offers many other advantages over traditional FM radio: select from a much wider range of radio stations and after an initial station scan you can easily select your desired channels from an alphabetic and genre list of available stations.Connect USB and HDMI SourcesYou can connect USB sticks and portable hard drives to playback audio and MP4 video files. The iLX-702D is also equipped with an HDMI input to connect the optional Alpine DVD player DVE-5300 or any other portable media player with HDMI output. You can also connect your smartphone if an HDMI adapter for your phone model is available to enjoy the video or photo content on the Alpine screen (requires additional cables and adapters). The iLX-702D includes an HDMI output as well to connect a rear monitor system via HDMI.Note: The HDMI output is a pass-through of the HDMI input and can therefore not be used to output USB video content, Apple CarPlay or Android Auto content. High-end Sound Tuning OptionsThe iLX-702D puts the power of advanced sound processing in your car with BASS ENGINE SQ to maximise bass sound and overall tone balance, plus lots of custom tuning functions like Digital Time Correction, Digital X-Over and Dual 9-band Parametric EQ. Best of all, you can set them easily from your smartphone with the Alpine TuneIt App. You also get Media Xpander, 24-Bit DAC and 3 PreOuts (4 Volt) as well. Hi-Res Audio PlaybackThis Alpine unit can playback audio files in FLAC format – including 24/96 and 24/192 Hi-Res Audio compatibility. Online Navigation with Apple CarPlayWhen you’re driving, Maps helps you find the way to your destination with turn-by-turn spoken directions and new, easier-to-read visuals. When a turn is coming up, the view zooms in to show you exactly where to go. Along the way, large signs and arrows guide you in the right direction and let you know how long it’s going to take to get there. Looking for a gas station, restaurant, or coffee shop along your route? New buttons on the navigation screen help you quickly find the closest places and estimate how much time the detour will add to your trip. If you push the navigation hard-key on your iLX-702D, you directly active Apple CarPlay navigation without going through many menu points. Online Navigation with Android AutoLet Google Maps lead the way. It’s easy to get where you’re going with free voice-guided navigation, live traffic information, lane guidance, and more. Whether on your phone screen or on your car display, Android Auto was designed with safety in mind. With larger touch targets, a simplified interface, and easy-to-use voice actions, it's designed to minimize distraction so you can stay focused on the road. The iLX-702D works seamlessly with Android Auto and Google maps. Android Auto can even access the Alpine navigation antenna for highest positioning accuracy.GPS and Glonass CompatibleMore satellites equal higher navigation accuracy and a faster positioning fix. This Alpine product is compatible with GPS satellite signals and can also receive positioning data from Glonass satellites. This brings big advantages especially in an urban environment with many tall buildings and when driving next to high mountains. When using navigation with Apple CarPlay and Glonass you can benefit from this new improved compatibility. Built-in Bluetooth® TechnologyThe built-in Bluetooth® module allows wireless connection of a mobile phone for hands-free communication. A very intuitive user interface makes it very easy to set microphone and speaker volume. It also includes a speed dial function for the most frequently called numbers. Bluetooth® also enables audio streaming from the phone: audio content or even internet radio can be wirelessly transferred to your Alpine unit. Vehicle Data-Bus ConnectivityIf your car is equipped with parking sensors, you can continue to use this convenient function with your iLX-702D. Alpine offers vehicle data-bus interfaces to connect your navigation system to your vehicle. This enables compatibility with your vehicle’s steering wheel control buttons, display of air conditioning settings as well parking sensor display. You can even see navigation turn-by-turn arrows in your multi-function display in the instrument cluster (if the vehicle supports it). Drive-Assist CamerasA rear view camera is a great way to make reversing safer. The camera image automatically comes on when you shift into reverse, and distance guides that can be adjusted to match your car size will appear on the screen to help you safely park your car. Alpine offers a wide variety of front and rear facing cameras, including multi-view cameras with selectable viewing angles and touch-control from your screen. You can even view the camera screen and parking sensor screen simultaneously. FavouritesWouldn’t it be convenient to have an app that shows you all your favourite phone numbers, radio stations, frequent navigation destinations and more on a single glance?! Favourites is just that. Simply hold the audio button for one second to activate the Favourites view and you are ready to go. Voice ControlPush the VOICE button on your Alpine unit or your steering wheel buttons (if supported) to activate SIRI or OK Google. You can simply call people, enter navigation destinations, write and send messages or simply say the song or playlist you like to listen to – just to name a few examples. This is a very convenient way to control your Alpine system while keeping your eyes on the road.FEATURESReceiverCell Memory (FM: 24 / MW: 6 / LW: 6)Memory: Auto MemoryFind Mode: Local / DX SelectionRDSRDS functionality: PI, PS, AF, TA, TP, PTY, NEWS, RADIO TEXTDAB receiverDAB + receiver embeddedDAB + / DMB supportedDAB + Slideshow serviceDLS (Dynamic Label Service)DAB Service FollowingRDS Fallback (where available)Cache services: memory for 18Automatic Ensemble / Service MemorySearch servicePTY searchSearch by alphabetSelect the antenna power supplyBluetoothBuilt-in BLUETOOTH® moduleWide Band Speech TechnologyHFP (Hands-Free Profile) CompatibilityMusic playback: A2DP (Advanced Audio Distribution Profile) compatibilityAudio playback control: AVRCP (Audio / Video Remote Control Profile) Ver.1.5 CompatibilityAdvanced BLUETOOTH® technologyConnectivity: SSP (Simple Secure Pairing) is supportedSingle terminal profile: Hands free calling and music broadcastingPhone book: Phonebook synchronizationSpeed ​​dial: 4 preset numbers (per phone)Multiple Phone Number Registration: 5 phone numbers can be stored in one nameDevice name displayAutomatic responseCall history display: Dialed Calls / Received Calls / Missed CallsRepeat functionSpeech volume control: Enabled for outgoing and incoming callsDTMF (Touch-Tone) functionSignal strength indicatorBattery indicatorLanguage menu: 24 languagesFirmware update possibleMicrophone: The microphone is completeMade for iPod® / iPhone®Compatibility for iPod / iPhone: Compatible with all models except the first and second generationConnectivity: KCU-461iV / KCU-471i required (sold separately)Compatible with headset and video playbackAvailable Options: Music List / Artist / Album / Song / Podcast / Genre / Composer / AudiobookSearchView albumDirect Up / Down: Playlist / Artist / Album / Podcast / Genre / ComposerMIX (Shuffle) Play: Song, Albums, AllRepeatCharge the batteryConnectivityWorks with Apple CarPlay (requires iPhone with CarPlay enabled)Works with Android Auto (requires smartphone with Android Auto enabled)USB connectivityOnline navigation with Apple CarPlay and Android AutoIncludes GPS / Glonass Supported Navigation AntennaA button for direct access to navigation via CarPlay or Google MapsUSB Media ConnectionUSB connection: USB extension cable includedMusic playback: FLAC / MP3 / WMA / AACVideo Playback: MP4File / Folder Search by nameTag Info SearchMap Up / DownMIX random playRepetitionAdjust the soundBass Engine SQBass Engine ™ ProAdjusts the subwoofer levelSelect subwoofer phase4V High Voltage PredictureEqualizer: Flat, Pop, Rock, News, Jazz, Electro Dance, Hip Hop, Easy Listening, Country, ClassicalDual HD EQ (9-band parametric EQ forward / backward)6 channel digital time correctionDigital CrossoverAdjustable sound adjustment per vehicle typeMediaXpander HDAdjust the sound level of your appsDownload sound settings dataSimple, step-by-step sound setupAlpine TuneIt App SupportOverviewOutput power: 4 x 50 W high power amplifierAdvanced Power ICScreen: 8-inch capacitive WVGA high resolution screenWhite LED Backlight System50/50 Split Screen: Left / Right Position SettingControl type: TouchFavoritesAutomatic change of settings for 2 usersAudiofilary design3 Predictive (4V, Forward / Backward / Subwoofer)AUX input: 1 A / V AUX input (3.5mm micro jack)Functionality of remote control of the steering wheelVehicle Display Interface Ready (UART connection)Remote control supportNavigation Guidance MixCamera Link & Embedded Control for Multi-View CameraSetting the camera lineRunning the rear camera screen automaticallySimple Mode & Info Mode selects the displayVisual EQAdjust contrastMain menu language: 24 languages ​​(for AV / Bluetooth), 29 languages ​​(Navigation menu and voice guidance)HourAutomatic dimmingSecurity code against the burglarsUpgradable FirmwarePower Antenna LeadRemote ignitionHDMI input (requires special Alpine HDMI connector)The Start-Stop motor does not affect the operation of the unitOptional DVD Player DVE-5300SPECIFICATIONSScreenScreen Size: 7-inch Capacitive WVGALCD Type: Transparent TN LCDOperating system: TFT Active MatrixNumber of image elements: 1,152,000 pixels (800 x 3 x 480)Illumination system: White LED backlightingEffective number of image elements: 99.99%Color system: NTSC, PALMax power at the exitMaximum Output Power: 4 x 50 WFM ReceiverReception range: 87.5-108.0 MHzUsable mono-sensitivity: 8.1 dBf (0.7 μV / 75 ohms)50 dB Muting Sensitivity: 12 dBf (1.1 μV / 75 ohms)Switch to alternative station: 80.0 dBSignal / noise ratio: 65.0 dBStereo separation: 35.0 dBReception Level: 2.0 dBMW receiverReception range: 531-1,602 kHzUsable sensitivity: 25.1 μV / 28 dBfLW receiverReceive range: 153 - 281 kHzUsable sensitivity (IEC standard): 31.6 μV / 30 dBUSBUSB Requirements: USB 2.0Maximum power consumption: 1,500 mA (CDP support)USB class: Mass storage, playback from the deviceFile system: FAT 16/32MP3 decoding: MPEG-1/2 AUDIO Layer-3WMA decoding: Windows Media ™ AudioAAC decoding: ACC-LC Format '' .m4a '' FileFLAC decodingNumber of channels: 2-channel (Stereo)Frequency Response: 5 - 20k Hz ± 1 dB * Frequency Response may vary depending on the encoding / bit rate softwareFully harmonic distortion (at 1kHz): 0.008%Dynamic range (at 1kHz): 95 dBSignal / noise ratio: 100 dBChannel Separation (at 1kHz): 85 dBGPS / GlonassGPS / Glonass compatible navigation antenna includedBluetoothBLUETOOTH® Version: Bluetooth V2.1 + EDROutput Power: +4 dBm Max. (Power class 2)HFP: HFP (Hands Free Profile)OPP (Object Push Profile)PBAP (Phone Book Access Profile)HSP (Head Set Profile)A2DP: A2DP (Advanced Audio Distribution Profile)AVRCP: AVRCP (Audio / Video Remote Control Profile)SPP (Serial Port Profile)Adjust the soundAdjusting the subwoofer level: 0 to +15Subwoofer phase adjustment: 0 ° or 180 °BASS ENGINE SQ: 5Mode, Level 0 to +6High Tire Filter: 20/25 / 31.5 / 40/50/63/80/100/125/160/200 HzSlope Filter: Off / -6 / -12 / -18 / -24 dB / oct.High Tone Filter (Gain): -12 to 0 dBLow Tone Filter: 20/25 / 31.5 / 40/50/63/80/100/125/160/200 HzSlope Filter: Off / -6 / -12 / -18 / -24 dB / oct.Low Tone Filter (Gain): -12 to 0 dBTime correction: 0.0 - 9.9ms (0.1ms step)Dual HD EQ Forward + BackParametric Equalizer (Band 1): 20 - 100 HzParametric Equalizer (Band 2): 63 - 315 HzParametric Equalizer (Band 3): 125 - 500 HzParametric Equalizer (Band 4): 250 - 1k HzParametric Equalizer (Band 5): 500 - 2k HzParametric Equalizer (Band 6): 1k - 4k HzParametric Equalizer (Band 7): 2k - 7.2 kHzParametric Equalizer (Band 8): 5.8k - 12k HzParametric Equalizer (Band 9): 9k - 20k HzParametric Equalizer (Gain): -14 to +14Adjust the volume level: -14 to +14HDMIInput Format 720p / 480p / VGAOutput Format 480pOverviewPower Requirements: 14.4 V.DC (11-16V Permissible)Pre-output voltage (before "clipping"): 4 V / 10k ohmsMaximum mounting angle: 30 °DimensionsDin Size: 1DIN Case and 7 "Capacitive Touch ScreenHousing dimensions (W x H x D) mm: 178 x 50 x 164 mmDimensions of the mask (W x H x D) mm: 170 x 96 x 17 mm..

Alpine INE-W990HDMIDrive with a Clear View of Your Route and Map DetailsThe INE-W990HDMI features a 6.1-inch high-resolution touch screen for easy viewing of navigation maps, videos and much more. The user interface is very intuitive and easy to use, allowing easy access and quick switching of sources. You get a wide variety of advanced tuning features, including the ability to use the versatile Alpine TuneIt App with Facebook linkage.Excellent sound quality complements its wide compatibility, including built-in Bluetooth with Voice Dial Function and optional DVB-T and DAB+. The INE-W990HDMI also provides music and video playback from your iPhone/iPod, USB sticks and a DVD player for DVD-Video, CD, DivX, MP3, WMA and AAC playback.Packed with Advanced Features for More Enjoyable DrivingThe INE-W990HDMI gives you wide map coverage of almost all European countries, support for maps with 3D landmarks, highway mode, advanced address input and other sophisticated features. This Advanced Navi Station has everything you need, no matter what countries you travel in. It covers 46 Western and Eastern European countries with 29 languages for voice guidance and Text-To-Speech in 15 languages. Its enhanced POI database makes it easy to find your favourite places and to explore new areas you have never been to. It also provides a TMC tuner that always keeps you on the route with the least traffic activity. While using navigation, you get on-screen information of your audio source (such as radio frequency, track title, song title etc)Free map update within 30 days after first usageWithin 30 days after the installed unit’s first GPS fix, you can go to www.naviextras.com to check if there is a map update available and download it free of charge. This ensures that you have the latest map data after purchase.Highway ModeIn addition to a view of the map, this mode gives you various detailed information such as upcoming rest stops, restaurants and petrol stations. You can see the distance and estimate arrival time for more efficient route planning. HDMI ConnectionConnect your HDMI enabled smartphone or portable media player via HDMI connection to enjoy all your video content on the units high-resolution display. Full digital data transfer and the WVGA display ensure excellent image quality. An optional HDMI cable (KCU-610HD for iPhone, Sony and Motorola, etc or KCU-610MH for HTC, Samsung Galaxy, Sony Xperia, etc) is required. Media Master     The INE-W990HDMI features many different media options to choose from. It provides music and video playback from your iPhone/iPod, USB sticks and a DVD player (DVD-Video / CD / DivX / MP3 / WMA / AAC). Videos look great on the 6.1” WVGA display with Visual EQ mode selection. You can also stream music via the built-in Bluetooth module. Sound customising functions include MediaXpander, 6-Channel Time Correction, Pre-set Equaliser (10 modes) and 9-band EQ DAB/DAB+ TUNER   The INE-W990HDMI is compatible with the TUE-DAB1U (sold separately). Use the TUE-DAB1U DAB/DAB+ Receiver with direct touch control to add available stations to the unit's internal station list. Bluetooth® for Hands-free Calls and Music Enjoyment   Built-in Bluetooth® provides hands-free phone use with Simple Secure Pairing and 24-language support. You can stream music from your phone, and compatibility with AVRCP Ver. 1.4 makes searching your library easier than ever. Bluetooth® Voice Dial Function While connecting to a voice dial compatible hands-free phone, you can make a telephone call by voice dial operation. Ready for Rear Camera with Distance Guide Adding an Alpine rear view camera makes reversing and parking much easier and safer. Coloured pylons appear on the screen as distance guides, and can be adjusted to match your car. System Integration for Enhanced Driving Ease   Alpine makes it easy to integrate the INE-W990HDMI with the factory system in your car. We have interfaces that let you operate  functions via the steering wheel remote control and use a sub-display to view information from the head unit on the gauges. It’s all part of the security concept aimed at letting you keep your eyes on the road. Sound Tuning FeaturesThe INE-W990HDMI puts the power of advanced sound processing in your car with BASS ENGINE SQ to maximise bass sound and overall tone balance, plus lots of custom tuning functions like Digital Time Correction and 9-Band Parametric EQ. Best of all, you can control them easily from your smartphone with the Alpine TuneIt App. The unit features 24-Bit DAC and 4-volt PreOuts as well. Features & SpecificationsFEATURESTunerMemory Presets (FM:18 / MW:6 / LW:6)Memory: Auto MemorySeek Mode: Local / DX SelectionRDSRDS Functions: AF, TA, TP, PTY, NEWS, RADIO TEXTBLUETOOTH®Built-in BLUETOOTH® ModuleHands Free Calling: HFP (Hands Free Profile) CompatibleStreaming Music: A2DP (Advanced Audio Distribution Profile) CompatibleStreaming Music Control: AVRCP (Audio/Video Remote Control Profile) Ver.1.4 CompatibleAdvanced BLUETOOTH® TechnologyConnection: SSP (Simple Secure Pairing) SupportedIndividual Profile Connection: Hands Free Phone and Music StreamingPhone Book: Phone Book SynchronizationSpeed Dial: 4 Preset Memory (per phone)Multiple Phone Number Registration: 3 Phone Numbers can be stored for one nameDevice Name DisplayAuto AnswerCall History Display: Dialed Call / Received Call / Missed CallRedial FunctionSpeech Volume Level Adjustment: Possible for Outgoing and Incoming VolumeDTMF (Touch-Tone) FunctionSignal Strength IndicatorBattery Level IndicatorMenu Language Selection: 24 LanguagesFirmware UpdatableMicrophone: Microphone IncludedMade for iPod® / iPhone®Compatibility for iPod/iPhone: Made for iPod touch 5th/4th/3rd/2nd/1st Gen., iPod nano 7th/6th/5th/4th/3rd/ Gen., iPod classic 160GB/120GB/80GB, iPod with video, iPhone5S,iPhone5C, iPhone5, iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3GConnection: KCU-461iV/KCU-471i Required (Sold separately)Music & Video Playback CompatibleAvailable Selections: Playlist/Artist/Album/Song/Podcast/Genre/Composer/AudiobookAlphabet SearchArtwork DisplayDirect Up/Down: Playlist/Artist/Album/Podcast/Genre/ComposerM.I.X. (Shuffle) Play: Song, Albums, AllRepeatBattery ChargingAlpine TuneIt AppAlpine TuneIt App Ready with iPhone and AndroidSound Setting FunctionSound Setting Data Upload to Alpine Cloud Server (Data Sharing)Facebook NotificationCompatible for iPhone and Android Smartphones: Available on Apple App Store and Google Play StoreDisc PlayerDisc Type: DVD/CD PlayerDisc Playback Type: DVD-Video, CD, CD-R/RW, DVD±R/±RWPlayable Format: DVD-Video, CDDA, MP3/WMA/AAC, DivXM.I.X. Random PlayRepeatDVD Direct Menu ControlCD Text DisplayCD Text Name SearchDAC: 24 Bit DACNavigation FunctionMap Coverage: 46 Countries (Western and Eastern Europe)Menu Language: 29 LanguagesVoice Guidance Language: 29 Languages for Voice Guidance, 15 Languages for Text-to-Speech (TTS)Advanced Address SearchPost Code SearchFree Form SearchPartial Name Search Smart SearchAdvanced POI FunctionsSmart Routes using historic traffic patternsAdvanced Route PlanningEco Route Search7 Alternative Route RecommendationAdvanced TMC ModeMap Display Mode: 2D Heading Up, 2D North Up, 3DElevation Map Display:3D Motorway Junction View: Junction View with Sign PostDrive Lane SuggestionTunnel ModeHighway ModeVoice Guidance MixingText-to-SpeechDirect Phone Call from POI dataPositioning Sensor: GPSUSB Media ConnectionUSB Video playbackUSB Connection: USB Extension Cable IncludedMusic & Video Playback CompatibleMusic Playback: MP3/WMA/AAC PlaybackVideo Playback: DivX PlaybackFile/Folder Name SearchTag Info SearchFolder Up/DownM.I.X. Random PlayRepeatSound TuningBASS ENGINE SQBASS ENGINE PROSubwoofer Level AdjustmentSubwoofer Phase SelectEqualizer: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop,  Easy Listening, Country, Classical9-band Parametric Equalizer6-Channel Digital Time CorrectionDigital Crossover SettingCustomized Sound Setting by Car TypeMediaXpanderApplication Volume Level SettingSound Setting Data DownloadEasy, Step-by-Step Sound CustomizationAlpine TuneIt App readyGeneralPower Output: 4 x 50 W High Power AmplifierDisplay: 6.1 inch WVGA High Resolution DisplayWhite LED Backlighting SystemControl Type: TouchDisplay Colour Setting: 8 Colours (Blue/Light Blue/Turquoise/Green/Red/Amber/Dark Yellow/White) SelectableHigh Grade Audiophile DesignPreOut: 3 PreOuts (4V, Front/Rear/Subwoofer)AUX-Out: 1 Video OutputAUX-In: 1 A/V AUX InputsSteering Wheel Remote Control ReadyOEM Sub-display ReadyRemote Control ReadyNavigation Guidance MixCamera ConnectionCamera Guide Line AdjustmentRearview Camera Display Automatic Boot-upSimple Mode & Info Mode Display SelectionVisual EQLive Contrast AdjustmentMenu Language: 24 Languages (for AV/Bluetooth), 29 Language (Navigation Menu and Voice Guidance)ClockAuto DimmerSecurity Code Anti-theftFirmware UpdatablePower Antenna LeadRemote Turn-OnHDMI InputStart-Stop Engine unaffectedSPECIFICATIONSScreenScreen Size: 6.1 inch WideLCD Type: Transparent Type TN LCDOperation System: TFT Active MatrixNumber of Picture Elements: 1,152,000 pixels (800 x 3 x 480)Effective Number of Picture Elements: 99% or moreIllumination System: White LED BacklightingColour System: NTSC, PALMax Power Output RatingsMax Power Output: 4 x 50 WFM TunerTuning Range: 87.5 - 108.0 MHzMono Usable Sensitivity: 8.1 dBf (0.7 µV / 75 ohms)50dB Quieting Sensitivity: 12 dBf (1.1 µV / 75 ohms)Alternate Channel Selectivity: 80 dBSignal-to-Noise Ratio: 65 dBStereo Separation: 35 dBCapture Ratio: 2 dBMW TunerTuning Range: 531 - 1,602 kHzUsable Sensitivity (IEC Standard): 25.1 µV / 28 dBfLW TunerTuning Range: 153 - 281 kHzUsable Sensitivity (IEC Standard): 31.6 µV / 30 dBfDisc PlayerFrequency Response: 5 -20k Hz ±1 dBChannel Separation (at 1kHz): 85 dBDynamic Range (at 1kHz): 95 dBTotal Harmonic Distortion (at 1kHz): 0.008%Wow & Flutter (%WRMS): B.M.L.Signal-to-Noise Ratio: 100 dBHorizontal Resolution: 500 lines or greaterVideo Output Level: 1 Vp-p (75 ohms)Signal-to-Noise Ratio (Video): DVD: 60 dBUSBUSB Requirements: USB 1.1/2.0Max. Power Consumption: 1,000 mAUSB Class: Mass Storage Class, Play From DeviceFile System: FAT 16/32MP3 Decoding: MPEG-1/2 AUDIO Layer-3WMA Decoding: Windows Media™ AudioAAC Decoding: ACC-LC Format ??.m4a?? FileDivX Decoding: ??.divx??, ??.avi?? FileNumber of Channels: 2-Channel (Stereo)Frequency Response: 5 - 20k Hz ±1 dB *Frequency Response may differ depending on the encoder software/bit rate.Total Harmonic Distortion (at 1kHz): 0.008%Dynamic Range (at 1kHz): 95 dBSignal-to-Noise Ratio: 100 dBChannel Separation (at 1kHz): 85 dBGPSGPS Antenna Type: Micro-strip Planar AerialReception Frequency: 1575.42 ±1 MHzReception Sensitivity: -130 dB MaximumReception Method: Parallel 12 ChannelsBLUETOOTH®BLUETOOTH® Version : Bluetooth V2.1+EDROutput Power: +4 dBm Max. (Power class 2)HFP (Hands Free Profile)HSP (Head Set Profile)OPP (Object Push Profile)PBAP (Phone Book Access Profile)A2DP (Advanced Audio Distribution Profile)AVRCP (Audio/Video Remote Control Profile)Sound TuningSubwoofer Level Adjustment: 0 to +15Subwoofer Phase Setting: 0° or 180°High Pass Filter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 HzHigh Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.High Pass Filter (Gain): -12 to 0 dBLow Pass Filter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 HzLow Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB/oct.Low Pass Filter (Gain): -12 to 0 dBTime Correction: 0.0 - 9.9ms (0.1ms step)Parametric Equalizer (Band 1): 20 - 100 HzParametric Equalizer (Band 2): 63 - 315 HzParametric Equalizer (Band 3): 125 - 500 HzParametric Equalizer (Band 4): 250 - 1k HzParametric Equalizer (Band 5): 500 - 2k HzParametric Equalizer (Band 6): 1k - 4k HzParametric Equalizer (Band 7): 2k - 7.2 k HzParametric Equalizer (Band 8): 5.8k - 12k HzParametric Equalizer (Band 9): 9k - 20k HzParametric Equalizer (Gain): -7 to +7Parametric Equalizer (Bandwidth): 1, 2, 3Application Volume Level Setting: -14 to +14HDMIInput Format 720p/480p/VGAOutput Format 480p/VGAGeneralPower Requirement: 14.4 V.DC (11-16V allowable)Pre Output Voltage (Before Clipping): 4 V / 10k ohmsMaximum Mounting Angle: 30°Weight: 2.12 kgDimensionsDin Size: 2DINChassis Size (W x H x D) mm: 178 x 100 x 165 mmNose Piece Size (W x H x D) mm: 170 x 96 x 11.5 mm ..

7-inch Touch Screen Navigation for Audi A4 / A5with TomTom maps, compatible with Apple CarPlay and Android Auto - X702D-A4RAlpine introduces the 2nd generation Alpine Style system for the Audi A4 (Model Year 2007-2015), A5 (Model Year 2016-2017)Get Apple CarPlay, Android Auto, Spotify, Waze, DAB+, USB video and much more for your Audi A4 / A5.The built-in iGo Primo nextgen navigation system features 3 years free-of-charge map updates and is now compatible with driver information display to view turn-by-turn arrows. All system components are designed to fit perfectly in existing installation locations and integrate fully with the vehicle’s electronic systems. High Resolution Touch ScreenThe 7-inch (17.8cm) high-resolution display allows full operation of the system via touch-screen technology and features the latest video technology for outstanding picture clarity, contrast and resolution. This allows navigation maps to be displayed in stunning detail, while movies or video clips become a real cinematic experience. The user interface is very intuitive and is designed to perfectly integrate into your vehicle. You’ll soon appreciate the ease of use and convenience of direct touch operation in your Audi. Steering Wheel Control ButtonsThe Alpine system is connected to your steering wheel control buttons. This means you do not lose this convenient feature when upgrading to Alpine and you will have full control over volume, phone, audio track forward/backward and many other commands. You can even activate voice control for Apple CarPlay and Android Auto right from your steering wheel. Alpine Control PanelThe original audio control panel is replaced by an Alpine panel that allows direct access to audio sources, navigation, rear view camera and more. It is designed to integrate perfectly into your vehicle’s dashboard. Driver Information DisplayThe X702D-A4R is linked to the driver information display in the instrument cluster. It can display radio station names, audio sources, caller names and much more. It is now also possible to display turn-by-turn arrows of the built-in iGo navigation system or Android Auto based navigation apps. Warning MessagesAudi uses the main display to show vehicle settings and warning messages (such as low oil level). The Alpine system is fully compatible with the Audi electronic systems and can therefore display all menus and warnings. You can also display air condition and heater settings, seat heating settings and many more (depends on original equipment). Sound System Adapter for AudiThe adapter KWE-DY01G6 is needed, if your Audi A4 is equipped with an Audi sound system (Audi Sound 9VD or B&O 9VK). It allows you to connect the X702D-A4R to the factory sound system. It is an attenuator which matches the more powerful Alpine Navigation System to the OEM amplifier. Premium Sound QualityAlpine is known worldwide for excellent sound quality. Our audio specialists engineered this system with the greatest attention to detail, from selection of high-grade components to precision audio tuning, to deliver a truly high-end sound experience for your Audi. The system also offers many sound adjustment functions such as digital time correction and professional equalization to allow users to adjust the system to their own preferences. Parking SupportThe X702D-A4R can be equipped with Alpine reversing and multi-view cameras that can be controlled right from the touch-screen display. The system is also compatible with the car’s parktronic system, which can be displayed simultaneously with the parking camera or stand-alone. We even redesigned the parktronic display in the 2nd generation system to show much greater detail. KIT-R1AU Optional Alpine Camera Installation Kit for AudiThe optional rear-view camera system provides parking safety with cutting-edge camera technology. The rear-view camera automatically activates when reversing. You not only have a clear view to the rear, you can also see useful distance guides that are programmed to exactly match the Audi's measurements for easier parking. Your Personal Media Expert Big Screen EntertainmentThe Alpine system allows you to enjoy movies, music videos or TV shows from many different sources, such as DVDs from the optional optical drive, USB sticks, the latest smartphones with HDMI output or portable video devices (optional cables or adapters are required). You can also connect your iPod touch or iPhone via HDMI to enjoy your video content on the high-resolution 7-inch display. Alpine even offers an all-new DVB-T2 tuner (TUE-T220DV) if you like to watch TV programs while you are waiting in traffic jams. For driving safety, the video playback feature is only available if the vehicle is not in motion. Works with Apple CarPlayThe innovative X702D-A4R with Apple CarPlay compatibility brings you a smarter way to use your iPhone on the road. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use maps, listen to music and access messages with just a word or a touch. You can even enjoy Spotify, internet radio or podcasts while on the road for a truly connected experience. Simply connect your CarPlay enabled iPhone to the USB port of your Alpine and you are ready to go. Works with Android AutoAndroid Auto was designed with safety in mind. With a simple and intuitive interface, integrated steering wheel controls, and powerful new voice actions, it's designed to minimize distraction so you can stay focused on the road. Android Auto automatically brings you useful information, and organizes it into simple cards that appear just when they're needed. Both Apple CarPlay and Android Auto can access the navigation antenna of the X702D-A4R for improved accuracy when using the navi apps. SpotifyYou can launch the Spotify app through Apple CarPlay and Android Auto and enjoy online music on your Alpine. You can fully control the app through your 7-inch touch-screen. The app works with Spotify regular and premium accounts, but offers different control options depending on the account level. Online Navigation with WazeWaze is the world’s largest community-based traffic and navigation app. Join other drivers in your area who share real-time traffic and road info, saving everyone time and gas money on their daily commute. Get alerted before you approach police, accidents, road hazards or traffic jams, all shared by other drivers in real-time. Waze is now available for Android Auto. Built-in Bluetooth® TechnologyThe built-in Bluetooth® module allows wireless connection of a mobile phone for hands-free communication, while frequent software updates ensure full compatibility with the latest phones. A very intuitive user interface makes operation extremely easy. Bluetooth® also enables audio streaming from the phone: audio content or even internet radio can be wirelessly enjoyed on the Alpine system. DAB/DAB+ Digital RadioThe built-in DAB/DAB+/DMB tuner uses the most advanced digital technology to deliver radio reception with outstanding, noise-free sound quality. DAB also offers many other advantages over traditional FM radio: choose from a much wider range of radio stations and after the initial station scan easily select your desired channels from an alphabetic or genre list of available stations. Hi-Res Audio PlaybackThis Alpine unit can playback audio files in FLAC format – including 24/96 and 24/192 Hi-Res Audio compatibility. Optional DVD PlayerUpgrade your Alpine infotainment system with DVD playback capability. The DVE-5300X is designed to fit exactly behind the audio control panel to be easily reached from the driver’s seat. It uses HDMI technology for stunning image quality and can be fully controlled from the touch screen or the Alpine control panel. The DVD Player provides DVD, CD, MP3, DivX and many more playback formats. Audiophile Grade Sound System UpgradeThe optional digital amplifier and high performance speaker system upgrade bring a truly amazing sound experience to your A4. Creating the full sound system requires the SPC-100AU Front Speaker Upgrade kit plus the SPC-200AU Sound System package. Built-in iGo Primo NextGen NavigationThe iGo Primo NextGen navigation is currently one of the best navigation software on the market. Combined with Alpine’s powerful hardware and processing power, you get a highly accurate and super fast navigation system for your car. For example, calculating a route from Munich to Paris takes just a few seconds. The system is packed with tons of useful and unique navigation features, from partial address input with automatic detection, TMC route guidance, 3D landmark icons and much more. It also includes hundreds-of-thousands of POIs, to make it easy to find restaurants and any kind of public places near you. Important Navigation FeaturesExtensive map database of 48 European countriesMap updates can be purchased at any time online through naviextras.comUpdates can be purchased by country and by region.This saves cost by updating only what is necessary.Address search with postcode input (including 7-digit UK postcodes)Smart routes: the system database stores historic traffic patterns and uses them to choose the best route depending on the time of day and day of weekHigh-resolution maps TomTom Maps with 3 Years Free-of-charge updatesA navigation system is only as good as its map database: the X702D-A4R includes TomTom maps for an awesome map coverage of 48 European countries. Within 3 years after the first navigation fix, you can go to alpine.naviextras.com to download map updates free of charge for your Alpine unit – you can even do so without any limitation on how often you update. After 3 years have passed, you can download regional map packages or the full European map update based on your needs for very reasonable cost. GPS and Glonass CompatibleMore satellites equal higher navigation accuracy and a faster positioning fix. This Alpine product is compatible with GPS satellite signals and can also receive positioning data from Glonass satellites. This brings big advantages especially in an urban environment with many tall buildings and when driving next to high mountains. When using navigation with Apple CarPlay and Android Auto you can also benefit from this new improved compatibility. FEATURES Tuner Memory Pre-sets (FM: 24 / MW: 6 / LW: 6) Memory: Auto Memory Seek Mode: Local / DX Selection RDS RDS Functions: PI, PS, AF, TA, TP, PTY, NEWS, RADIO TEXT DAB Tuner DAB+ Tuner Built-in DAB+/DMB Supported DAB+ Slideshow Service DLS (Dynamic Label Service) DAB Service Following RDS Fallback (where available) Service Pre-set: 18 Pre-set Memory Auto Ensemble/Service Memory Service Search Function PTY Search Function Alphabet Search Function Antenna Power Supply Selection BLUETOOTH® Built-in BLUETOOTH® Module Wide Band Speech Technology HFP (Hands-Free Profile) Compatible Streaming Music: A2DP (Advanced Audio Distribution Profile) Compatible Streaming Music Control: AVRCP (Audio / Video Remote Control Profile) Ver.1.5 Compatible Advanced BLUETOOTH® Technology Connection: SSP (Simple Secure Pairing) Supported Individual Profile Connection Hands Free Phone and Music Streaming Phone Book: Phone Book Synchronization Speed Dial: 4 Pre-set Memory (per phone) Multiple Phone Number Registration: 5 Phone Numbers can be stored for one name Device Name Display Auto Answer Call History Display: Outgoing Calls / Incoming Calls / Missed Calls Redial Function Speech Volume Level Adjustment: Possible for Outgoing and Incoming Volume DTMF (Touch-Tone) Function Signal Strength Indicator Battery Level Indicator Menu Language Selection: 24 Languages Firmware Updatable Made for iPod® / iPhone® Compatibility for iPod/iPhone: compatible with all models except 1st and 2nd generation iPhone Connection: KCU-461iV / KCU-471i Required (Sold separately) Music & Video Playback Compatible with KCU-461iV only Available Selections: Playlist / Artist / Album /Song / Podcast / Genre / Composer / Audiobook Alphabet Search Artwork Display Direct Up / Down: Playlist / Artist / Album / Genre / Composer M.I.X. (Shuffle) Play: Song, Albums, All Repeat Battery Charging Connectivity Works with Apple CarPlay (requires CarPlay enabled iPhone) Works with Android Auto (Requires Android Auto enabled smartphone) Navigation Functions Map Coverage: 48 Countries (Western and Eastern Europe) Menu Language: 29 Languages Voice Guidance Language: 29 Languages for Voice Guidance, 15 Languages for Text-to-Speech (TTS) Advanced Address Search Post Code Search Free Form Search Partial Name Search Advanced POI Functions Smart Routes: Smart Routes using historic traffic patterns Advanced Route Planning Eco Route Search 7 Alternative Route Recommendation Advanced TMC Mode Map Display Mode: 2D Heading Up, 2D North Up, 3D 3D City Mode: 3D Building/Icon Display Elevation Map Display: 3D maps with elevation mode 3D Motorway Junction View: Junction View with Sign Post Drive Lane Suggestion Tunnel Mode Highway Mode Voice Guidance Mixing Text-to-Speech Direct Phone Call from POI data 3 Positioning Sensors: GPS / Glonass, Gyroscope, Vehicle Speed Pulse USB Media Connection USB Connection: USB Extension Cable Included Music Playback: FLAC/MP3/WMA/AAC compatible Video Playback: MP4 compatible File / Folder Name Search Tag Info Search Folder Up / Down M.I.X. Random Play Repeat Sound Tuning Bass Engine SQ Bass Engine™ Pro Subwoofer Level Adjustment Subwoofer Phase Select 2V High Voltage PreOut Equalizer: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, Classical Dual HD EQ (9-band Parametric Equalizer front/rear) 6 Channel Digital Time Correction Digital Crossover Setting Customized Sound Setting by Car Type MediaXpander HD Application Volume Level Setting Sound Setting Data Download Easy, Step-by-Step Sound Customization Alpine TuneIt App ready General Power Output: 4 x 50 W High Power Amplifier Advanced Power IC Display: 7′′ Capacitive WVGA High Resolution Display White LED Backlighting System 50/50 Split Screen: Left / Right Position Changeable Control Type: Touch, Drag, Flick My Favourites Function Automatic Setting Change for 2 Users High Grade Audiophile Design 3 PreOuts (2V, Front / Rear / Subwoofer) KTX-PRE1 Required (Sold separately) AUX-In: 1 A/V AUX Input (3.5mm micro jack) Steering Wheel Remote Control Function OEM Sub-display Function Remote Control Ready Navigation Guidance Mix Camera Connection & Built-in Controls for Multi-View Cameras / compatible with original camera Camera Guide Line Adjustment Rear-view Camera Display Automatic Boot-up Multi Camera Selector Interface KCX-C250MC ready Simple Mode & Info Mode Display Selection Visual EQ Live Contrast Adjustment Menu Language: 24 Languages (for AV / Bluetooth), 29 Languages (Navigation Menu and Voice Guidance) Clock Auto Dimmer Anti-theft security code Firmware Updatable Power Antenna Lead Remote Turn-On HDMI Input / Output (Alpine Special HDMI connector required) HDMI Selector Interface KCX-630HD Ready Engine Start-Stop unaffected CAN Connection Interface Included Ready for optional DVD Player DVE-5300X Map & Database Online Map Update via alpine.naviextras.com Featuring TomTom Maps 3 Years free of charge map update (multiple updates possible) Installation Includes installation brackets, wiring harness and CAN bus interface for complete installation. SPECIFICATIONS Screen Screen Size: 7-inch Capacitive WVGA LCD Type: Transparent Type TN LCD Operation System: TFT Active Matrix Number of Picture Elements: 1,152,000 pixels (800 x 3 x 480) Illumination System: White LED Backlighting Effective Number of Picture Elements: 99.99% Colour System: NTSC, PAL Max Power Output Ratings Max Power Output: 4 x 50 W FM Tuner Tuning Range: 87.5 - 108.0 MHz Mono Usable Sensitivity: 8.1 dBf (0.7 µV / 75 ohms) 50dB Quieting Sensitivity: 12 dBf (1.1 µV / 75 ohms) Alternate Channel Selectivity: 80 dB Signal-to-Noise Ratio: 65 dB Stereo Separation: 35 dB Capture Ratio: 2 dB MW Tuner Tuning Range: 531 - 1,602 kHz Usable Sensitivity (IEC Standard): 25.1 µV / 28 dBf LW Tuner Tuning Range: 153 - 281 kHz Usable Sensitivity (IEC Standard): 31.6 µV / 30 dBf USB USB Requirements: USB 2.0 Max. Power Consumption: 1,500 mA (CDP Support) USB Class: Mass Storage Class, Play From Device File System: FAT 16/32 MP3 Decoding: MPEG-1/2 AUDIO Layer-3 WMA Decoding: Windows Media™ Audio AAC Decoding: ACC-LC format ′′.m4a′′ file Flac Decoding USB Video playback (AVI/MP4/MKV file with H.264 Video and MP3/AAC Audio) Number of Channels: 2-Channel (Stereo) Frequency Response: 5 - 20k Hz ±1 dB *Frequency Response may differ depending on the encoder software/bit rate Total Harmonic Distortion (at 1kHz): 0.008% Dynamic Range(at 1kHz): 95 dB Signal-to-Noise Ratio: 100 dB Channel Separation (at 1kHz): 85 dB GPS / Glonass GPS / Glonass compatible navigation antenna included BLUETOOTH® BLUETOOTH® Version: Bluetooth V3.0+EDR Output Power: +4 dBm Max. (Power class 2) HFP: HFP (Hands Free Profile) OPP (Object Push Profile) PBAP (Phone Book Access Profile) HSP (Head Set Profile) A2DP: A2DP (Advanced Audio Distribution Profile) AVRCP: AVRCP (Audio/Video Remote Control Profile) SPP (Serial Port Profile) Sound Tuning Subwoofer Level Adjustment: 0 to +15 Subwoofer Phase Setting: 0° or 180° BASS ENGINE SQ: 5Mode, Level 0 to +6 High Pass Filter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz High Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB/oct. High Pass Filter (Gain): -12 to 0 dB Low Pass Filter: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 / 100 / 125 / 160 / 200 Hz Low Pass Filter (Slope): Off / -6 / -12 / -18 / -24 dB/oct. Low Pass Filter (Gain): -12 to 0 dB Time Correction: 0.0 - 9.9ms (0.1ms step) Dual HD EQ Front + Rear Parametric Equalizer (Band 1): 20 - 100 Hz Parametric Equalizer (Band 2): 63 - 315 Hz Parametric Equalizer (Band 3): 125 - 500 Hz Parametric Equalizer (Band 4): 250 - 1k Hz Parametric Equalizer (Band 5): 500 - 2k Hz Parametric Equalizer (Band 6): 1k - 4k Hz Parametric Equalizer (Band 7): 2k - 7.2k Hz Parametric Equalizer (Band 8): 5.8k - 12k Hz Parametric Equalizer (Band 9): 9k - 20k Hz Parametric Equalizer (Gain): -14 to +14 Application Volume Level Setting: -14 to +14 HDMI Section Input Format 720p/480p/VGA Output Format 480p General Power Requirement: 14.4 V. DC (11-16V allowable) Pre Output Voltage (Before Clipping): 2 V / 10k ohms Maximum Mounting Angle: 30° Dimensions X702D-A4 / X702D-A5: Fits for Audi A4 / A5 left hand drive X702D-A4R: Fits for Audi A4 / A5 right hand drive Chassis Size (W x H x D) mm: 178 x 50 x 164 mm ..
