Focal Utopia M 3.5WM Midrange Car Speaker Driver
- Stock Availability: Pre-Order - Contact Us
- Item Condition : New
- Model: 3.5WM-MIDRANGE-M
- SKU: FOCAL35WM
- 1 Year Warranty
Available Options
 | You are being offered an Installation Service at an additional cost. If you select the installation option, the purchased product will be professionally Installed at your home or workplace by our network of Qualified & Accredited Installation Engineers. You will be contacted by a member of our installation booking team after you have placed an order (Within 72 hours). To be sure we cover your area, please contact us before selecting this option. OEM products are all designed to seamlessly integrate into the vehicle alongside other factory fitted technology. |
 | Enjoy the peace of mind that comes with a professional, risk-free installation service, by placing your trust in a certified installer. Car Communications are a certified national installer. |
MIDRANGE SPEAKER DRIVER
The design of this ultra-compact midrange speaker driver was made possible thanks to the exclusive use of our new ‘M'-profile 'W' sandwich cone, combined, amongst other things, with our TMD® surround and a red neodymium motor, Focal's signature. Our ears being particularly sensitive around 4kHz, this 3.5” midrange will surprise you with its extreme softness and striking realism.
'M'-profile 'W' sandwich cone
The new, patented, ‘M'-profile cone is the result of many years of research and our expertise in materials and their geometry. The innovative ‘M’-profile, made from a single piece, means it is incredibly rigid and perfectly combines the three criteria essential for creating an “ideal” speaker driver: rigidity, lightness and damping. The result is an extremely linear frequency response, a low distortion rate and better sound dispersion.
Upon listening, this cone delivers striking realism and level of detail, that transports you into the heart of music.
TMD® surround
Originally developed for the Sopra line of high-fidelity loudspeakers, our TMD® (Tuned Mass Damper) surround has a unique profile, designed to better control the effects of resonance and to drastically reduce the distortion associated with deformations of the cone. The speaker driver takes advantage of this patented technology by spreading better defined and very realistic midranges’ frequencies.
Progressive spider
The progressive spider used on all our Utopia drivers is built around a progressive section that reproduces all the impact of the bass whilst optimising the linearity, precision and dynamics of the sound.
Key Features:
- M'-profile 'W' cone
- 'TMD' suspension
- Frequency response: 200Hz - 10kHz
- Shallow depth
- QTY - 1
Technical Specifications:
- Midrange (3.5") 87.5 mm
- Voice coil diameter (1.8") 45 mm
- Motor Neodymium
- Cone 'M'-profile 'W'
- Suspension Tuned Mass Damper (TMD®)
- Impedance 4Ω
- Max. power 100W
- Nom. power 50W
- Sensitivity (2.83 V/1 m) 88dB
- Frequency response 200Hz - 10kHz
- Accessories
- Mounting screws supplied
- Optional grilles
| Refer to installation documentation supplied with the Focal speakers |
