Dashmount 711069 Upper Console Mounting Bracket Land Rover Freelander 2007 >
- Stock Availability: Out Of Stock
- Item Condition :
- Model: 711069
Mounting Bracket
The (711069) dashmountTM bracket will enable you to fit your car phone cradle, phone holder or iPod cradle without having to make screw holes in the dashboard fascia of your vehicle. All DashmountTM mounting brackets are TUV safety approved, beware of cheaper imitations!
Check the compatibility section if supported with your car make and model
Made from top quality steel that has a special black powder coating to ensure a neat finish. These brackets have pre drilled holes and slots to suit most of the common hands free car kit cradles and phone holders on the market. The brackets utilise either tape and grippers or the screws that are already in your vehicle but are hidden from sight. Fitting instructions are included with each bracket purchased - some trim removal may be required.
All DashmountTM brackets should be installed by a suitably qualified person. Neither Car Communications or DashmountTMaccepts any responsibility for any damage caused to the vehicle whilst attempting to install the bracket.
Easy-Fit robust and stylish DashmountTM mounting bracket, giving a damage free installation of mobile phone cradles, iPod Car Kit cradles and other portable devices offering easy access while giving an integrated look with your dashboard and interior. DashmountTM brackets are vehicle specific resulting in optimum design and simple installation for your particular car make and model.
Key Features
- Damage free installation of mobile phone cradle, ipod cradles or other portable devices
- Easy-Fit robust and stylish Dashmount mounting bracket
- TUV safety approved
If you are unsure about the suitability of this product with your car please submit an enquiry form by clicking ask us about this item found at the top of this page.
Dashmount 711069
Land Rover Compatibility Chart | |||
Car Model | Year | Description | Notes |
Freelander | 2007 > | 1 |
1. May require trim removal tools. Check installation section for further details
If you are unsure about the compatibility of this product with your car please submit an enquiry form by clicking ask us about this item found at the top of this page.
You may require trim removing tools for installing this product.
Step 1: Remove the rubber mat from the fascia pen tray.
Step 2: Remove the Torx screws beneath.
Step 3: Remove the dash top speaker grille trim by unclipping at the windshield end and sliding back away from the console fascia.
Step 4: Remove the two Torx screws in the upper part of the trim, that are revealed.
Step 5: Unclip the fascia by sliding a trim tool in behind each lower corner of the fascia panel and then lift upwards towards the screen
Step 6: Remove the two left hand Torx screws securing the audio unit.
Step 7: Locate the bracket with the guide pin in the recess.
Step 8: Refit the Torx and slide the panel back in to place around the plate so that it emerges from the audio aperture.
Step 9: Refit the screws and trim.
If you require help with installation please submit our enquiry form by clicking ask us about this item found at the top of this page after you have purchased the item. We will more than happily provide free telephone or email support.
