Phoenix Gold ZX4CXS ZX-Series 4 inch 2-WAY COAXIAL SPEAKER

Phoenix Gold ZX4CXS 4 inch (102mm) 2-way Coaxial Speaker combines sleek design with superior audio performance.

The ZX4CXS speakers are expertly crafted to deliver a smooth and efficient sound experience. They are packed into slim dimensions that seamlessly integrate into your car’s audio system. With 50W RMS power handling and a peak power of 150W, this speaker delivers exceptional sound clarity and deep bass.

Experience superior sound quality with the Phoenix Gold ZX4CXS, a high-performance 4 inch 2-way coaxial speaker designed for clarity and efficiency. This compact yet powerful speaker system delivers crisp highs, rich midrange, and a balanced sound profile, making it a perfect upgrade for any car audio setup.

With 50W RMS power handling and a peak power of 150W, the ZX4CXS provides impressive audio performance in a small form factor. The 85dB sensitivity ensures efficient sound output, while the 125Hz – 20kHz frequency response captures a full range of sound.

Built for durability and precision, the ZX4CXS features a laminated-treated paper cone for natural sound reproduction, a 19mm balanced driver Mylar tweeter for crisp highs, and a polyimide voice coil for enhanced performance. The triple-layer UV-treated foam surround enhances longevity, and the rigid powder-coated steel frame ensures stability.

The ZX4CXS is designed for easy installation and includes speaker grills for protection and style.

Specifications:

• Speaker Type: 2-Way Coaxial Speaker
• Speaker Size: 4 inch (102mm)
• Frequency Response: 125Hz – 20kHz
• Power Handling (RMS): 50W
• Power Handling (MAX): 150W
• Impedance: 4Ω
• Sensitivity: 85dB (1W/1m)
• Voice Coil: 1 inch (25mm)
• Mounting Depth: 43mm
• Mounting Diameter: 93mm
• Outer Diameter: 102mm (130mm including ears)
• Speaker Grills: Included
• Unit: Sold as pairs
• Weight (Each Speaker): 0.4 kg


T/S PARAMETERS

• Re: 3.6 Ohm
• Fs: 125 Hz
• Qms: 6.178
• Qes: 2.172
• Qts: 1.607
• Cms: 269 μM/N
• Vas: 1.224 L
• BL: 2.686 Tm
• Sd: 56.75 cm²
• Mms: 4.678 g
• EBP: 57
