Reversing Rear View Camera Kit for 2018+ Mercedes Sprinter with MBUX head unit
- Stock Availability: In Stock
- Item Condition : New
- Model: RVC-SPRINTER-18
- SKU: RVC-SPRINTER-18
- 1 Year Warranty
Available Options
Optional Installation Package
You are being offered an Installation Service at an additional cost. If you select the installation option, the purchased product will be professionally Installed at your home or workplace by our network of Qualified & Accredited Installation Engineers. You will be contacted by a member of our installation booking team after you have placed an order (Within 72 hours). To be sure we cover your area, please contact us before selecting this option.
We also offer Discounted competitive rates if Installations are carried out at our Workshop in Blackburn. Please contact us for a competitive quote.
Please choose the correct option from the list
Commercial vehicles & Motorhomes - Vans (Small & large), Mini Vans, Taxis, Buses, Mini Buses, Trucks, HGV's, Motorhomes, Campervans
Non- Commercial - Standard Sized 2/4/5 Door Family cars (not used for commercial purposes)
Please note: Incorrect selection will be charged the difference before the install takes place. If you are unsure of the correct selection, please contact us first.
- Description
- Vehicle Compatibility
- Installation
- Specifications
- User Manuals
- Reviews
- Product Related Question?
Rear View Camera Kit For 2018+ Mercedes Sprinter
An integrated high-quality rear view camera kit, designed to work with the factory fitted MBUX 7" & 10.25" Head unit. The Kit includes either a Heavy Duty Camera or a Brake Light Camera, please select your required option from the the Recommended Add-Ons above. Either of the selected cameras will provide a high quality image on the factory fitted screen.
Brake Light Camera
A Colour rear view camera for Mercedes Sprinter vans, featuring a 1/3” colour CMOS camera lens for best image reproduction quality. This unit replaces the original Brake Light.
This reversing camera is specially designed for Mercedes vehicles. The camera includes a 15M video extension RCA cable kit which allows easy plug and play installation. Just remove the existing brake light and replace it with the brake light reversing camera, which is also equipped with a Brake light. The camera is water proof and shock tested.
Features
- NTSC
- IP69 waterproof rating
- Night vision IR Lamp
- Lens Angle (In Degrees): 120
- CMOS Lens
- Certificates : FCC,CE, E-mark,ISO9001,TS16949, RoHs
- Dimensions 263mm x 32mm
Heavy Duty Commercial Camera
This backup camera with robust stainless housing is 120 degrees with night vision for commercial vehicles. The waterproof rating is IP69K. It has unique design and moulding. It also has heating function. S3, CE, E-mark, FCC, TS16949 are available.
Features
- Camera
- Sensor 1/3 CMOS
- TV System NTSC/PAL
- Camera Ir LED 20pcs IR lamp with excellent night vision
- Min Illumination 0.1Lux@(F1.2,AGC ON);
- Electronic Shutter Auto:PAL 1/50s(NTSC 1/60s)~1/100,000s
- Focus 2.8mm
- Lens Interface M12
- F.O.V 120° (D)、95°(H)、70°(V)
- Backlight Compensation Auto
- Resolution 700TVL(AHD 720P)
- Signal to Noise ratio Better than 48dB
- Interface Connect
- 4 Pin Aviation Female Interface
- Video Output 1Vp-p Composite Output(75Ω)
- Audio Input Options
- Audio Output Options
- General
- Material Metal
- Operating Temperature -30℃~70℃
- Usage For passenger vehicles
- Operating Voltage DC9-36V±10%(From Reversing Monitor DC12V)
- Waterproof IP69K
- External Dimensions 92.06*47.8mm *72.2(L*W*H)
Bolt-ON Camera
This miniature 155° wide-angle substructure NTSC camera is a rear view camera with unlimited areas of application in the car, bus, mobile home, truck or trailer. The matt black plastic housing is particularly weatherproof, IP69K waterproof and very sturdy. Optionally, two different auxiliary lines (narrow / wide) can be faded into the video signal, which enables the viewer to park better. The delivery is complete with an 8 meter extension cable with high-quality copper strands.
Features
- 2 different auxiliary lines: switched off at the factory (can be switched on)
- black matt plastic housing with stainless steel fastening
- Mirrored image reproduction (adjustable)
- Image display rotated 180° (adjustable)
- Image sensor type 1/4 '' 1233 HD Colour CMOS Low Light Sensor
- NTSC video signal output
- Resolution 960H480V pixels
- DIN protection class IP69K
- 800 TV lines
- Exposure 60 fields per seconds
- Signal to noise ratio >46dB
- Dynamic Range >74dB
- Light sensitivity <0.01 Lux / F1.2
- Output signal 1.0Vp-p, 75 OHM
- Automatic white balance
- Automatic video level adjustment
- Operating voltage 12 volts DC
- Power consumption 25-55mA
- Diagonal viewing angle 188°
- Horizontal viewing angle 155°
- Vertical viewing angle 113°
- Camera dimensions 25.8 x 28.2mm and 20.8mm high
- 8mm mounting hole
- Working temperature -40°C to +75°C
- Storage temperature -60°C to +105°C
- E certified
Benefits of having a reversing rear view camera kit
- Guidelines can be really helpful so the driver can accurately estimate the width of the vehicle parking space whilst reversing.
- The driver can see any obstructions behind the vehicle during the reversing manoeuvre
- The driver can see any any blind spots which are not visible to the driver
- Greater vehicle safety management during reversing manoeuvres
- Makes reversing much safer and more convenient
*Installation is optional via the dropdown
![]() | Refer to the compatibility section to check your vehicle variant is supported. |
NOTE: A reversing camera kit is ONLY a Parking Aid and should not be relied on solely. Please check your surroundings at all times before carrying out a Reversing Manoeuvre. Where Guide lines are included, the guide lines are generic to all vehicles and hence fixed width and not adjustable to the width of the vehicle.
Product Compatibility Chart
Make | Model | Variations | Years | Radio | Notes |
Mercedes-Benz | Sprinter |
W907/W910 (2019 > ) | 2018 onward |
MBUX Sprinter
| Compatible with MBUX 7" & 10.25" Screen |
If you are unsure about the suitability of this product please contact us via the ask a question link at the top of this page or telephone us and we will gladly assist you.

Factory fitted In-car Infotainment systems and their wiring can be complex, so we always recommend that you have your installation carried out by a qualified installer. If you wish, Car Communications can arrange for your RVC Kit to be installed at an address of your choice anywhere in the UK. Please select from addons options above before adding the purchase to your cart. During the checkout process you will be asked for your preferred date(s) and time for the installation.
For added peace of mind, our products can be professionally installed at your home or workplace anywhere in the UK by our qualified and accredited network of engineers.
RVC Spec | |
Reversing Camera Features | Reg Plate, Boot Handle & Brake Light Camera, Reversing Camera Kit |
